The Fast and Easy Digital Tracker

                 Brochure.pdf  |  Support

If you do not already have the free Adobe Acrobat Reader you may obtain it here:

Applications

FASTRAK has been considered the industry standard of motion tracking for over 10 years. FASTRAK is the perfect solution for the position/orientation measuring requirements of applications and environments. Ideal for head tracking, hand tracking, instrument tracking, biomechanical analysis, graphic and cursor control, sterotaxic localization, telerobotics, digitizing and pointing.





Stylus Options - ST8 or ST3

Adding a stylus allows you to turn your FASTRAK into a free form digitizer ideal for creating files that can be used in the most popular computer graphics programs.

The FASTRAK accurately computes the position and orientation of a small receiver as it moves through space. This device virtually eliminates the problem of latency as it provides dynamic, real time six degrees of freedom measurement of position (X, Y, and Z Cartesian coordinates) and orientation (azimuth, elevation, and roll), and it is the most accurate electromagnetic tracking system available.

FASTRAK is the perfect solution for interfacing with Virtual Reality environments and controlling simulator projectors or other applications where real time response is critical. It is also ideal for measuring range of motion or limb rotation in biomedical research. It is a fast, accurate, easy to use, and effective method of capturing motion data on any non-conductive object.

The FASTRAK system utilizes a single transmitter and can accept data from up to four receivers. The use of advanced digital signal processing (DSP) technology provides an update rate of 120 Hz (with a single receiver) and a remarkable 4ms latency. The data is then transmitted over a high speed RS-232 interface at up to 115.2K baud or a USB interface. If your application requires using the system in close proximity to a CRT, FASTRAK has special circuitry to allow you to Synchronize with it for improved performance.

FASTRAK uses patented low-frequency magnetic transducing technology, so there is no need to worry about maintaining a clear line-of-sight between receiver and transmitter. Polhemus has eliminated the problem of signal blocking and interference that distorts sonic or laser devices.

For complete details on components, features, applications and specifications,

please download the FASTRAK brochure.
